Magneto Ball Bearings

These magneto ball bearings are commonly used in small motors and power tools, to support smooth, high-speed rotation with minimal friction.

42 products

Loading filters…

Magneto Ball Bearings

What is a magneto ball bearing?

A magneto ball bearing is a small, single-row radial ball bearing with a separable outer ring. It looks like a deep groove ball bearing, but one shoulder of the outer ring is reduced so the ring can be lifted off the rest of the assembly.

Key features:

  • Separable design - the outer ring comes apart from the inner ring, balls, and cage
  • Load capacity - handles radial loads plus axial loads in one direction only
  • Usually used in pairs - mounted facing each other to locate the shaft both ways
  • Compact sizes - typically bores of about 3mm to 20mm

The name comes from their original use in magnetos, the ignition generators of early engines.

Why are magneto ball bearings essential?

Magneto bearings are valuable wherever space is tight and smooth, precise rotation is needed.

Their main benefits are:

  • Easy assembly - the inner ring and ball set onto the shaft while the outer ring goes into the housing, reducing damage during installation
  • Precision - paired bearings can be preloaded to remove play, giving accurate shaft positioning
  • Quiet, low-vibration running - at high speeds

This makes them important in small electric motors, generators, measuring instruments, gyroscopes, textile spindles, power tools, and small pumps.

The main types of magneto bearings

These are a few standard series, and within each, several material and precision options:

  • E Series - (E5, E8, E10, E12, E15, E17, E20) - the most common range; the number usually equals the bore in mm, and the outer ring is separable.
  • EN Series - a closely related range with its own dimensions, which can vary slightly by manufacturer.
  • BO Series (BO15, BO17) - a traditional range often found in older or industrial equipment.

Other variations include:

  • Material - chrome steel as standard, stainless steel for corrosive conditions
  • Cage - pressed steel, machined brass, or polyamide
  • Precision class - standard up to high-precision grades such as ABEC 5/7

How to choose the right magneto bearing?

Work through these points in order:

  • Dimensions - match bore outside diameter and width to your shaft and housing; check the reference on the old bearing or the equipment manual.
  • Loads and speed - confirm the catalogue load ratings and speed suit your application, remembering they work in opposed pairs
  • Environment - choose stainless steel for humid or corrosive settings, and check cage and lubricant for extreme temperatures.
  • Precision - standard tolerances suit general motors and tools; instruments and high-speed spindles need higher grades.
  • Consistency - stick to the same series and a reputable brand, since dimensions can differ slightly between manufacturers

FAQ - All you need to know about magneto bearings

Can a magneto bearing replace a deep groove ball bearing?

Not usually, as it takes axial load in one direction only and is designed for pairs.

Why are they mounted in pairs?

To locate the shaft in both axial directions and allow a controlled preload for play-free running.

Do they need lubrication?

Yes, grease or oil. Most are open (unsealed), so the surrounding design must keep them lubricated and clean.

How do I find the right reference?

Check the marking on the old bearing, the machine’s documentation or the manufacturer’s catalogue, or ask a bearing supplier if the marking is worn.
