SKU: 20210-TVP-MB
20210TVP Barrel Roller Bearing with Cylindrical Bore 50x90x20mm - Allow 2-3 Days
20210TVP Barrel Roller Bearing with Cylindrical Bore 50x90x20mm - Allow 2-3 Days
Regular price
€174,95
ex VAT
Regular price
Sale price
€174,95
ex VAT
In stock
Price Break
3+
€132,68
4+
€125,23
9+
€123,74
19+
€122,25
29+
€120,76
39+
€119,26
49+
€111,81
59+
€110,32
249+
€108,83
499+
€107,34
999+
€104,36
Description
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a cylindrical bore and a solid window cage made from glass fibre reinforced polyamide. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures up to +120 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 90mm
- Width:
- 20mm
- Clearance:
- * Standard
Technical
Technical
| d | 50mm |
|---|---|
| D | 90mm |
| B | 20mm |
| r min | 1.1mm |
| D1 | 79.5mm |
| da min | 57mm |
| Da max | 83mm |
| ra max | 1mm |
| Dynamic Load Cr | 58500 N |
| Static Load C0r | 68000 N |
| Fatigue limit load Cur | 7000 N |
| Limiting speed nG | 3600 rpm |
| Weight | 0.499 kg |
