SKU: 20B-1-SYNO-10FT-RENOLD
Renold SYNO 20B-1 BS Simplex Roller Chain 1-1/4mm Pitch - 10 Feet Length
Renold SYNO 20B-1 BS Simplex Roller Chain 1-1/4mm Pitch - 10 Feet Length
Regular price
€1.530,66
ex VAT
Regular price
Sale price
€1.530,66
ex VAT
Equivalent to: SNX20B-1
In stock
Price Break
10+
€1.362,29
19+
€1.285,75
29+
€1.270,45
39+
€1.255,14
49+
€1.239,83
74+
€1.224,53
99+
€1.148,00
199+
€1.132,69
249+
€1.117,38
499+
€1.102,08
999+
€1.071,46
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Simplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX20B-1
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 31.75mm = 1.25 (1-1/4) inch
Technical
Technical
| Pitch (A) | 1.25 inch |
|---|---|
| Pitch (A) | 31.75mm |
| Inside Width min (B) | 19.56mm |
| Roller Diameter max (C) | 19.05mm |
| Plate Height max (D) | 26.42mm |
| Plate Width Inner max (E) | 4.62mm |
| Plate Width Outer max (F) | 3.61mm |
| Pin Diameter max (G) | 10.19mm |
| Pin Length max (H1) | 39.8mm |
| Connecting link extension max (J) | 2.7mm |
| ISO606 Tensile strength min | 95000 N |
| Weight | 3.85 kg/m |
