KOYO 30204JR Narrow Section Steering Head Set Taper Roller Bearing 20x47x15.25mm

Name: KOYO 30204JR Narrow Section Steering Head Set Taper Roller Bearing 20x47x15.25mm
Brand: Koyo
SKU: 30204.JR.KOY
Price: 12.95 EUR
Availability: InStock

€12,95 ex VAT

Sale Sold out

In stock

Price Break

10+ €9,12

20+ €8,61

30+ €8,51

40+ €8,40

50+ €8,30

75+ €8,20

100+ €7,69

200+ €7,58

250+ €7,48

500+ €7,38

1000+ €7,17

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Narrow Section Taper Roller Bearings: Typically used in motorcycle steering heads these bearings are manufactured with large bore to outside diameter ratios and low overall height to permit use in space restricted applications, typically in motorcycle and automotive installations
Benefits: Narrow section, low height, large bore to diameter ratio

Brand / Quality:: Koyo - High Quality
Inside Diameter:: 20mm
Outside Diameter:: 47mm
Width:: 15.25mm
Seals / Shields:: None

Technical

d	20mm
D	47mm
T	15.25mm
B	14mm
C	12mm
r min	1mm
r1 min	1mm
Dynamic load Cr	27 kN
Static load Cor	27.2 kN
Speed in grease	8700 rpm
Speed in oil	12000 rpm
a	11.8mm
da min	25.5mm
db max	27mm
Da max	41.5mm
Da min	39mm
Db min	44mm
Ca min	2mm
Cb min	3mm
ra max	1mm
rb max	1mm
e	0.35
Y1	1.74
Y0	0.96
Mass	0.127 kg
