SKU: 320/28JR-KOY
KOYO 320/28JR Narrow Section Steering Head Set Taper Roller Bearing 28x52x16mm
KOYO 320/28JR Narrow Section Steering Head Set Taper Roller Bearing 28x52x16mm
Regular price
€14,95
ex VAT
Regular price
Sale price
€14,95
ex VAT
In stock
Price Break
10+
€10,73
20+
€10,13
30+
€10,01
40+
€9,89
50+
€9,77
75+
€9,65
100+
€9,04
200+
€8,92
250+
€8,80
500+
€8,68
1000+
€8,44
Description
Description
|
Narrow Section Taper Roller Bearings: Typically used in motorcycle steering heads these bearings are manufactured with large bore to outside diameter ratios and low overall height to permit use in space restricted applications, typically in motorcycle and automotive installations Benefits: Narrow section, low height, large bore to diameter ratio |
- Brand / Quality:
- Koyo - High Quality
- Inside Diameter:
- 28mm
- Outside Diameter:
- 52mm
- Width:
- 16mm
- Seals / Shields:
- None
Technical
Technical
| d | 28mm |
|---|---|
| D | 52mm |
| T | 16mm |
| B | 16mm |
| C | 12mm |
| r min | 1mm |
| r1 min | 1mm |
| Dynamic load Cr | 35.2 kN |
| Static load Cor | 44 kN |
| Speed in grease | 7500 rpm |
| Speed in oil | 10000 rpm |
| a | 12.7mm |
| da min | 33.5mm |
| db max | 33mm |
| Da max | 46.5mm |
| Da min | 45mm |
| Db min | 49mm |
| Ca min | 3mm |
| Cb min | 4mm |
| ra max | 1mm |
| rb max | 1mm |
| e | 0.43 |
| Y1 | 1.39 |
| Y0 | 0.77 |
| Mass | 0.15 kg |
