• SKF 52207 Double Thrust Ball Bearing with Flat Seats 30x62x34mm
1 1

SKU: 52207-SKF

SKF 52207 Double Thrust Ball Bearing with Flat Seats 30x62x34mm

SKF 52207 Double Thrust Ball Bearing with Flat Seats 30x62x34mm
€73,95 ex VAT
€73,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €55,87
19+ €52,73
29+ €52,10
39+ €51,47
49+ €50,84
74+ €50,22
99+ €47,08
199+ €46,45
249+ €45,82
499+ €45,20
999+ €43,94
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Double Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of five parts, a top, bottom and middle plate with annular grooves in them and two caged ball bearing assemblies that are sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in two directions. Clearance is provided in the bore of Centre of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
Brand / Quality:
SKF - High Quality
Inside Diameter:
30mm
Outside Diameter:
62mm
Width:
34mm
Technical
d 30mm
D 62mm
H 34mm
Dynamic load C 35.1 kN
Static load Co 73.5 kN
Fatigue load limit Pu 2.7 kN
Minimum load factor A 0.028
Reference speed 4000 rpm
Limiting speed 5600 rpm
Weight 0.41 kg
D1 37mm
B 8mm
r1r2 1mm
r3r4 0.3mm
da 35mm
Da max 46mm
ra max 1mm
rb max 0.3mm
