SKF 53204 Single Thrust Ball Bearing with Spherical Housing Seat U204 20x40x17mm
SKF 53204 Single Thrust Ball Bearing with Spherical Housing Seat U204 20x40x17mm
Regular price
€42,95
ex VAT
Regular price
Sale price
€42,95
ex VAT
In stock
Price Break
10+
€32,47
19+
€30,64
29+
€30,28
39+
€29,91
49+
€29,55
74+
€29,18
99+
€27,36
199+
€27,00
249+
€26,63
499+
€26,27
999+
€25,54
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 20mm
- Outside Diameter:
- 40mm
- Width:
- 17mm
Technical
Technical
| d | 20mm |
|---|---|
| D | 40mm |
| H1 | 17mm |
| Dynamic load C | 22.5 kN |
| Static load Co | 40.5 kN |
| Fatigue load limit Pu | 1.53 kN |
| Minimum load factor A | 0.0085 |
| Reference speed | 6000 rpm |
| Limiting speed | 8000 rpm |
| Weight | 0.1 kg |
| Seating washer | U204 |
| d1 | 40mm |
| D1 | 22mm |
| D2 | 30mm |
| D3 | 42mm |
| H | 14.73mm |
| C | 5mm |
| R | 36mm |
| s | 18mm |
| r1r2 min | 0.6mm |
| da max | 32mm |
| Da max | 30mm |
| ra max | 0.6mm |
