SKU: 53207?EU

53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm

Name: 53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm
Brand: Gen
SKU: 53207?EU
Price: 34.95 EUR
Availability: InStock

€34,95 ex VAT

Sale Sold out

In stock

Price Break

10+ €26,18

19+ €24,71

29+ €24,42

39+ €24,12

49+ €23,83

74+ €23,54

99+ €22,07

199+ €21,77

249+ €21,48

499+ €21,18

999+ €20,59

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 35mm
Outside Diameter:: 62mm
Width:: 22mm

Technical

d	35mm
D	62mm
H1	22mm
Dynamic load C	35.1 kN
Static load Co	73.5 kN
Fatigue load limit Pu	2.7 kN
Minimum load factor A	0.028
Reference speed	4000 rpm
Limiting Speed	5600 rpm
Weight	0.28 kg
Seating Washer	U207
d1	62mm
D1	37mm
D2	48mm
D3	65mm
H	19.87mm
C	7mm
R	50mm
s	24mm
r1r2 min	1mm
da max	51mm
Da max	48mm
ra max	1mm
