SKF 53209 Single Thrust Ball Bearing with Spherical Housing Seat U209 45x73x24mm
SKF 53209 Single Thrust Ball Bearing with Spherical Housing Seat U209 45x73x24mm
Regular price
€122,95
ex VAT
Regular price
Sale price
€122,95
ex VAT
In stock
Price Break
10+
€93,60
19+
€88,34
29+
€87,29
39+
€86,24
49+
€85,19
74+
€84,14
99+
€78,88
199+
€77,83
249+
€76,78
499+
€75,72
999+
€73,62
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 73mm
- Width:
- 24mm
Technical
Technical
| d | 45mm |
|---|---|
| D | 73mm |
| H1 | 24mm |
| Dynamic load C | 39 kN |
| Static load Co | 86.5 kN |
| Fatigue load limit Pu | 3.2 kN |
| Minimum load factor A | 0.038 |
| Reference speed | 3600 rpm |
| Limiting speed | 5000 rpm |
| Weight | 0.39 kg |
| Seating washer | U209 |
| d1 | 73mm |
| D1 | 47mm |
| D2 | 60mm |
| D3 | 78mm |
| H | 21.3mm |
| C | 7.5mm |
| R | 56mm |
| s | 26mm |
| r1r2 min | 1mm |
| da max | 62mm |
| Da max | 60mm |
| ra max | 1mm |
