SKU: 53211?SKF

SKF 53211 Single Thrust Ball Bearing with Spherical Housing Seat U211 55x90x30mm

Name: SKF 53211 Single Thrust Ball Bearing with Spherical Housing Seat U211 55x90x30mm
Brand: SKF
SKU: 53211?SKF
Price: 168.95 EUR
Availability: InStock

€168,95 ex VAT

Sale Sold out

In stock

Price Break

10+ €128,11

19+ €120,91

29+ €119,47

39+ €118,03

49+ €116,59

74+ €115,15

99+ €107,96

199+ €106,52

249+ €105,08

499+ €103,64

999+ €100,76

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: SKF - High Quality
Inside Diameter:: 55mm
Outside Diameter:: 90mm
Width:: 30mm

Technical

d	55mm
D	90mm
H1	30mm
Dynamic load C	61.8 kN
Static load Co	146 kN
Fatigue load limit Pu	5.4 kN
Minimum load factor A	0.11
Reference speed	2800 rpm
Limiting speed	4000 rpm
Weight	0.75 kg
Seating washer	U211
d1	90mm
D1	57mm
D2	72mm
D3	95mm
H	27.35mm
C	9mm
R	72mm
s	35mm
r1r2 min	1mm
da max	76mm
Da max	72mm
ra max	1mm
