SKF 53212 Single Thrust Ball Bearing with Spherical Housing Seat U212 60x95x31mm
SKF 53212 Single Thrust Ball Bearing with Spherical Housing Seat U212 60x95x31mm
Regular price
€202,95
ex VAT
Regular price
Sale price
€202,95
ex VAT
In stock
Price Break
10+
€154,14
19+
€145,48
29+
€143,75
39+
€142,02
49+
€140,28
74+
€138,55
99+
€129,89
199+
€128,16
249+
€126,43
499+
€124,70
999+
€121,23
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 95mm
- Width:
- 31mm
Technical
Technical
| d | 60mm |
|---|---|
| D | 95mm |
| H1 | 31mm |
| Dynamic load C | 62.4 kN |
| Static load Co | 150 kN |
| Fatigue load limit Pu | 5.6 kN |
| Minimum load factor A | 0.12 |
| Reference speed | 2800 rpm |
| Limiting speed | 3800 rpm |
| Weight | 0.82 kg |
| Seating washer | U212 |
| d1 | 95mm |
| D1 | 62mm |
| D2 | 78mm |
| D3 | 100mm |
| H | 28.02mm |
| C | 9mm |
| R | 72mm |
| s | 32.5mm |
| r1r2 min | 1mm |
| da max | 81mm |
| Da max | 78mm |
| ra max | 1mm |
