SKF 53309 Single Thrust Ball Bearing with Spherical Housing Seat U309 45x85x33mm
SKF 53309 Single Thrust Ball Bearing with Spherical Housing Seat U309 45x85x33mm
Regular price
€175,90
ex VAT
Regular price
Sale price
€175,90
ex VAT
In stock
Price Break
10+
€156,55
19+
€147,76
29+
€146,00
39+
€144,24
49+
€142,48
74+
€140,72
99+
€131,93
199+
€130,17
249+
€128,41
499+
€126,65
999+
€123,13
Couldn't load pickup availability
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 85mm
- Width:
- 33mm
Technical
Technical
| d | 45mm |
|---|---|
| D | 85mm |
| H1 | 33mm |
| Dynamic load C | 76.1 kN |
| Static load Co | 153 kN |
| Fatigue load limit Pu | 5.6 kN |
| Minimum load factor A | 0.12 |
| Reference speed | 2800 rpm |
| Limiting speed | 4000 rpm |
| Weight | 0.83 kg |
| Seating washer | U309 |
| d1 | 85mm |
| D1 | 47mm |
| D2 | 65mm |
| D3 | 90mm |
| H | 30.13mm |
| C | 10mm |
| R | 64mm |
| s | 25mm |
| r1r2 min | 1mm |
| da max | 69mm |
| Da max | 65mm |
| ra max | 1mm |
