53320 Budget Single Thrust Ball Bearing with Spherical Housing Seat U320 100x170x64mm

Name: 53320 Budget Single Thrust Ball Bearing with Spherical Housing Seat U320 100x170x64mm
Brand: Gen
SKU: 53320?EU
Price: 404.95 EUR
Availability: InStock

€404,95 ex VAT

Sale Sold out

In stock

Price Break

10+ €307,67

19+ €290,39

29+ €286,93

39+ €283,47

49+ €280,02

74+ €276,56

99+ €259,27

199+ €255,82

249+ €252,36

499+ €248,90

999+ €241,99

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 100mm
Outside Diameter:: 170mm
Width:: 64mm

Technical

d	100mm
D	170mm
H1	64mm
Dynamic load C	229 kN
Static load Co	610 kN
Fatigue load limit Pu	19.6 kN
Minimum load factor A	1.9
Reference speed	1400 rpm
Limiting Speed	1900 rpm
Weight	5.95 kg
Seating Washer	U320
d1	170mm
D1	103mm
D2	135mm
D3	175mm
H	59.2mm
C	18mm
R	125mm
s	46mm
r1r2 min	1.5mm
da max	142mm
Da max	135mm
ra max	1.5mm
