SKF 53320 Single Thrust Ball Bearing with Spherical Housing Seat U320 100x170x64mm
SKF 53320 Single Thrust Ball Bearing with Spherical Housing Seat U320 100x170x64mm
Regular price
€818,95
ex VAT
Regular price
Sale price
€818,95
ex VAT
In stock
Price Break
10+
€623,02
19+
€588,02
29+
€581,02
39+
€574,02
49+
€567,02
74+
€560,02
99+
€525,02
199+
€518,02
249+
€511,02
499+
€504,02
999+
€490,02
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 100mm
- Outside Diameter:
- 170mm
- Width:
- 64mm
Technical
Technical
| d | 100mm |
|---|---|
| D | 170mm |
| H1 | 64mm |
| Dynamic load C | 229 kN |
| Static load Co | 610 kN |
| Fatigue load limit Pu | 19.6 kN |
| Minimum load factor A | 1.9 |
| Reference speed | 1400 rpm |
| Limiting speed | 1900 rpm |
| Weight | 5.95 kg |
| Seating washer | U320 |
| d1 | 170mm |
| D1 | 103mm |
| D2 | 135mm |
| D3 | 175mm |
| H | 59.2mm |
| C | 18mm |
| R | 125mm |
| s | 46mm |
| r1r2 min | 1.5mm |
| da max | 142mm |
| Da max | 135mm |
| ra max | 1.5mm |
