SKU: 61802-2RS1-EU
68022RS Budget Rubber Sealed Thin Section Deep Groove Ball Bearing 15x24x5mm
Equivalent to: 61802NSE 61802DU 61802RS 618022RSH 61802P 61802RSR 61802LU 6802NSE 6802DU 6802RS 68022RSH 6802P 6802RSR 6802LU 618022NSE 61802DDU 618022RS 618022RSH 61802PP 618022RSR 61802LLU 618022RS2 61802RS2 618022RSH 618022RS1
In stock
Price Break
Description
|
Budget Thin Section Rubber Sealed Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with rubber seals inserted into the outer raceway and in contact with the inner race providing protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing. |
Equivalent: 61802NSE 61802DU 61802RS 618022RSH 61802P 61802RSR 61802LU 6802NSE 6802DU 6802RS 68022RSH 6802P 6802RSR 6802LU 618022NSE 61802DDU 618022RS 618022RSH 61802PP 618022RSR 61802LLU 618022RS2 61802RS2 618022RSH 618022RS1
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 15mm
- Outside Diameter:
- 24mm
- Width:
- 5mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- * Standard
Technical
| d | 15mm |
|---|---|
| D | 24mm |
| B | 5mm |
| r min | 0.3mm |
| Dynamic load Cr | 2.1 kN |
| Static load Cor | 1.25 kN |
| Speed in grease | 28000 rpm |
| Speed in oil | 33000 rpm |
