SKU: AXK1103-NTN
NTN AXK1103 Needle Roller Cage Only 17x30x2mm - Allow 2-3 Days
NTN AXK1103 Needle Roller Cage Only 17x30x2mm - Allow 2-3 Days
Regular price
€4,95
ex VAT
Regular price
Sale price
€4,95
ex VAT
Low stock
Price Break
3+
€3,66
4+
€3,45
9+
€3,41
19+
€3,37
49+
€3,33
99+
€3,29
499+
€3,08
999+
€3,04
1999+
€3,00
2999+
€2,96
4999+
€2,88
Description
Description
|
NTN Needle Roller Thrust Bearing Cages: These cages are engineered for precision, durability, and smooth operation under demanding conditions. Designed by one of the world’s leading bearing manufacturers, these thrust cages provide exceptional rigidity and load-carrying capability while keeping friction to a minimum.
Perfect for applications where space is limited but performance cannot be compromised, NTN thrust cages deliver reliable axial support in high-speed, high-load environments. Their optimised cage design ensures accurate needle roller guidance, reduced heat generation, and long service life. Benefits: High axial load capacity, low friction, compact and lightweight design |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 17mm
- Outside Diameter:
- 30mm
- Width:
- 2mm
Technical
Technical
| Dc1 - Inside diameter | 17mm |
|---|---|
| Dc - Outside diameter | 30mm |
| Dw - Roller Width | 2mm |
| AS washer reference | AS1103 |
| WS inner ring reference | WS81103 |
| GS outer ring reference | GS81103 |
| Ea - Rollers reference outer diameter | 28.5mm |
| Eb - Rollers reference inner diameter | 19.2mm |
| Ca - Dynamic axial load rating | 11.9 kN |
| C0a - Static axial load rating | 39.5 kN |
| Cua - Limit axial load rating | 4.8 kN |
| Grease lubrication limit speed | 2500 tr/min |
| Oil lubrication limit speed | 10000 tr/min |
| Tmin - Minimum operating temperature | -20 Deg C |
| tmax - Maximum operating temperature | +120 Deg C |
