SKU: BB-608-A500-70-ES
xiros xirodur BB608A50070ES Open Type Polymer Ball Bearing with PEEK Cage and Stainless Steel Balls 8x22x7mm - Allow 2-3 Days
xiros xirodur BB608A50070ES Open Type Polymer Ball Bearing with PEEK Cage and Stainless Steel Balls 8x22x7mm - Allow 2-3 Days
Regular price
€45,07
ex VAT
Regular price
Sale price
€45,07
ex VAT
In stock
Price Break
10+
€40,11
19+
€37,86
29+
€37,41
39+
€36,96
49+
€36,51
74+
€36,06
99+
€33,80
199+
€33,35
249+
€32,90
499+
€32,45
999+
€31,55
Couldn't load pickup availability
Description
Description
|
IGUS xiros® xirodur® A500 Polymer Ball Bearings: These open type radial deep groove ball bearings consist of PEEK cages and stainless steel balls. The inner rings, outer rings and cages of these bearings are made of FDA-compliant plastics making these bearings suitable for use in the food industry. These bearings are suitable for high temperatures up to +150 deg C. Benefits: Made of FDA approved plastics, lubrication- and maintenance-free, corrosion-resistant, non-magnetic, washable, lightweight, high-temperature range, life time predictable. |
- Brand / Quality:
- Igus - High Quality
- Inside Diameter:
- 8mm
- Outside Diameter:
- 22mm
- Width:
- 7mm
- Seals / Shields:
- None
- Clearance:
- * Standard
- Temperature Range:
- High Temp
Technical
Technical
| d1 | 8mm |
|---|---|
| d2 | 22mm |
| b1 | 7mm |
| Max static axial load | 220 N |
| Static load capacity | 72 N |
| Dynamic load capacity | 97 N |
| Max speed | 2700 rpm |
| Race | A500 |
| Cage | PEEK |
| Ball material | Stainless Steel |
