BR607632 Machined Type Imperial Needle Roller Bearing Without Inner Ring 3-3/4x4-3/4x2 inch
BR607632 Machined Type Imperial Needle Roller Bearing Without Inner Ring 3-3/4x4-3/4x2 inch
Regular price
€112,95
ex VAT
Regular price
Sale price
€112,95
ex VAT
Equivalent to: HJ607632 HJ-607632 MR60 MR-60 SJ9648
In stock
Price Break
10+
€85,47
20+
€80,67
30+
€79,71
40+
€78,74
50+
€77,78
75+
€76,82
100+
€72,02
200+
€71,06
250+
€70,10
500+
€69,14
1000+
€67,22
Description
Description
|
Imperial Machined Type Needle Roller with Flanges: Supplied without the inner ring for instances where a mating bearing surface already exists or an inner ring is to be used & has the benefit of flanges in the outer race to compensate for small misalignments and small side loads. Benefits: Economical replacement, needles are retained within machined flange of the outer race. |
Equivalent: HJ607632 HJ-607632 MR60 MR-60 SJ9648
- Brand / Quality:
- IKO - High Quality
- Inside Diameter:
- 95.25mm = 3.75 (3-3/4) inch
- Outside Diameter:
- 120.65mm = 4.75 (4-3/4) inch
- Width:
- 50.8mm = 2 inch
Technical
Technical
| Fw | 3-3/4 inch |
|---|---|
| D | 4-3/4 inch |
| C | 2 inch |
| Dynamic Load Cor | 169000 N |
| Static Load Cr | 342000 N |
| Weight | 1.29 kg |
