SKU: GX120F-SKF
SKF GX120F Maintenance Free Thrust Spherical Plain Bearing 120x230x64mm
SKF GX120F Maintenance Free Thrust Spherical Plain Bearing 120x230x64mm
Regular price
€1.916,06
ex VAT
Regular price
Sale price
€1.916,06
ex VAT
Equivalent to: GE120AW GX120T
In stock
Price Break
10+
€1.705,29
19+
€1.609,49
29+
€1.590,33
39+
€1.571,17
49+
€1.552,01
74+
€1.532,85
99+
€1.437,05
199+
€1.417,88
249+
€1.398,72
499+
€1.379,56
999+
€1.341,24
Couldn't load pickup availability
Description
Description
SKF Spherical Plain Bearings: Maintenance-free spherical plain thrust bearings with sliding contact surface combination, steel/ PTFE composite. |
Equivalent: GE120AW GX120T
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 120mm
- Outside Diameter:
- 230mm
- Width:
- 64mm
Technical
Technical
| d | 120mm |
|---|---|
| D | 230mm |
| T | 64mm |
| Angle | 4 degree |
| Dynamic load | 880 kN |
| Static load | 1430 kN |
| dk | 250mm |
| d1 | 220mm |
| D1 | 145mm |
| B | 53.5mm |
| C | 50mm |
| r1 min | 1mm |
| s | 52.5mm |
| da min | 170mm |
| Da max | 190mm |
| ra max | 1mm |
| Weight | 14 kg |
