SKU: MFC55-RHP
RHP MFC55 Four Bolt Round Cast Iron Flanged Bearing Unit and 55mm Insert
RHP MFC55 Four Bolt Round Cast Iron Flanged Bearing Unit and 55mm Insert
Regular price
€181,02
ex VAT
Regular price
Sale price
€181,02
ex VAT
In stock
Price Break
10+
€161,11
19+
€152,06
29+
€150,25
39+
€148,44
49+
€146,63
74+
€144,82
99+
€135,77
199+
€133,95
249+
€132,14
499+
€130,33
999+
€126,71
Couldn't load pickup availability
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 55mm
- Style:
- MFC
- Pitch Circle Diameter:
- 152.4mm
Technical
Technical
| Bore | 55mm |
|---|---|
| L | 181mm |
| H | 127mm |
| J | 152.4mm |
| G | 12mm |
| A1 | 42.85mm |
| A4 | 15.9mm |
| A5 | 9.5mm |
| B | 65.07mm |
| s | 25.45mm |
| d1 | 75.34mm |
| Dynamic load | 48000 N |
| Static load | 33000 N |
| Rec max speed | 2800 rpm |
| Weight | 3.4 kg |
| Insert | <a href="advanced_search_result.php?keywords=1060-55G+insonly">1060-55G Click Here</a> |
| Casting group | 6 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
