SKU: MUCFPL206-SNR
SNR MUCFPL206 Metric Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with 30mm Bore Insert - Allow 2-3 Days
SNR MUCFPL206 Metric Thermoplastic Four Bolt Square Flanged Bracket Housing Unit with 30mm Bore Insert - Allow 2-3 Days
Regular price
€90,95
ex VAT
Regular price
Sale price
€90,95
ex VAT
In stock
Price Break
3+
€76,75
4+
€73,65
9+
€72,10
19+
€69,78
49+
€68,23
99+
€64,35
499+
€54,27
999+
€0,00
1999+
€0,00
2999+
€0,00
4999+
€0,00
Description
Description
SNR MUCFPL200 Four Bolt Square Thermoplastic Housing Unit: This housing is designed for durability in demanding environments. With a sturdy thermoplastic housing and a stainless steel insert ball bearing secured by socket set screws, this unit ensures reliable performance. Its innovative seal with slinger protects against contaminants, while the food-grade grease makes it ideal for food processing applications. Experience exceptional strength and reliability with this versatile housing unit.
Benefits: Durability, food-safe design, easy maintenance
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 30mm
- Temperature Range:
- -20 to 100 deg C
- Style:
- MUCFPL
- Colour:
- White
- Bolt Hole Centres:
- 83.0mm
Technical
Technical
| Bore | 30mm |
|---|---|
| A - Housing height | 31.5mm |
| A1 - Housing foot height / flange height | 14.3mm |
| A2 - Total height from mounting surface | 41.4mm |
| B - Width of Inner Ring | 38.1mm |
| d - Shaft diameter | 30mm |
| e - Distance mounting surface to bearing centre | 19.2mm |
| G - Grease fitting | 1/4-28 inch |
| J - Mounting holes distance | 83mm |
| L - Housing width / diameter | 107mm |
| N - Mounting hole dimension | 11mm |
| S - Distance front side/bearing centre | 15.9mm |
| C - Dynamic load rating | 16.7 kN |
| C0 - Static load rating | 9 kN |
| Operating temperature min. | -20 Deg C |
| Operating temperature max. | 100 Deg C |
| Mass | 0.5kg |
| Recommended tightening torque for set screw | 3.9 Nm |
