SKU: SSUCT.207
SSUCT207 Metric Stainless Steel Take Up Unit Housing with 35mm Bore Stainless Insert
SSUCT207 Metric Stainless Steel Take Up Unit Housing with 35mm Bore Stainless Insert
Regular price
€138,95
ex VAT
Regular price
Sale price
€138,95
ex VAT
Equivalent to: ST35
In stock
Price Break
3+
€105,11
4+
€99,20
9+
€98,02
19+
€96,84
49+
€95,66
99+
€94,48
499+
€88,57
999+
€87,39
1999+
€86,21
2999+
€85,03
4999+
€82,67
Description
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Equivalent: ST35
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 35mm
- Style:
- SSUCT
Technical
Technical
| d | 35mm |
|---|---|
| o | 16mm |
| g | 13mm |
| p | 64mm |
| q | 37mm |
| s | 22mm |
| b | 64mm |
| K | 12mm |
| e | 89mm |
| a | 102mm |
| w | 129mm |
| j | 37mm |
| l | 30mm |
| h | 78mm |
| Bi | 42.9mm |
| n | 17.5mm |
| Weight | 1.3 kg |
| Dynamic load | 2010 kgf |
| Static load | 1390 kgf |
| Rec max speed | 4500 rpm |
