SKU: SYF25TF-SKF
SKF SYF25TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 25mm
SKF SYF25TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 25mm
Regular price
€44,95
ex VAT
Regular price
Sale price
€44,95
ex VAT
In stock
Price Break
10+
€33,82
20+
€31,92
30+
€31,54
40+
€31,16
50+
€30,78
75+
€30,40
100+
€28,50
200+
€28,12
250+
€27,74
500+
€27,36
1000+
€26,60
Description
Description
|
SKF Y-bearing Plummer Block Units with a Cast Housing: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 25mm
- Style:
- SYF
- Bolt Hole Centres:
- 50.8mm
Technical
Technical
| d | 25mm |
|---|---|
| A | 36mm |
| A1 | 22mm |
| B | 34.1mm |
| H | 70.5mm |
| H1 | 36.5mm |
| J | 50.8mm |
| L | 70mm |
| G | M10 |
| G1 | 15mm |
| s1 | 19.8mm |
| Static load Cr | 7.8 kN |
| Dynamic load Cor | 14 kN |
| Fatigue load limit Pu | 0.335 kN |
| Limiting speed | 7000 rpm |
| Weight | 0.52 kg |
| Housing | SYF505 |
| Insert | YAR205-2F |
