SKU: SYF30TF-SKF
SKF SYF30TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 30mm
SKF SYF30TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 30mm
Regular price
€51,95
ex VAT
Regular price
Sale price
€51,95
ex VAT
In stock
Price Break
10+
€39,45
20+
€37,24
30+
€36,79
40+
€36,35
50+
€35,91
75+
€35,46
100+
€33,25
200+
€32,80
250+
€32,36
500+
€31,92
1000+
€31,03
Description
Description
|
SKF Y-bearing Plummer Block Units with a Cast Housing: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 30mm
- Style:
- SYF
- Bolt Hole Centres:
- 76.2mm
Technical
Technical
| d | 30mm |
|---|---|
| A | 40mm |
| A1 | 25mm |
| B | 38.1mm |
| H | 83mm |
| H1 | 42.9mm |
| J | 76.2mm |
| L | 98mm |
| G | M10 |
| G1 | 15mm |
| s1 | 22.2mm |
| Static load Cr | 11.2 kN |
| Dynamic load Cor | 19.5 kN |
| Fatigue load limit Pu | 0.475 kN |
| Limiting speed | 6300 rpm |
| Weight | 0.9 kg |
| Housing | SYF506 |
| Insert | YAR206-2F |
