SKU: SYF40TF-SKF
SKF SYF40TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 40mm
SKF SYF40TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 40mm
Regular price
€108,95
ex VAT
Regular price
Sale price
€108,95
ex VAT
In stock
Price Break
10+
€82,67
20+
€78,03
30+
€77,10
40+
€76,17
50+
€75,24
75+
€74,31
100+
€69,67
200+
€68,74
250+
€67,81
500+
€66,88
1000+
€65,03
Description
Description
|
SKF Y-bearing Plummer Block Units with a Cast Housing: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Style:
- SYF
- Bolt Hole Centres:
- 88.9mm
Technical
Technical
| d | 40mm |
|---|---|
| A | 48mm |
| A1 | 30mm |
| B | 49.2mm |
| H | 99mm |
| H1 | 49.2mm |
| J | 88.9mm |
| L | 116mm |
| G | M12 |
| G1 | 20mm |
| s1 | 30.2mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 30.7 kN |
| Fatigue load limit Pu | 0.8 kN |
| Limiting speed | 4800 rpm |
| Weight | 1.5 kg |
| Housing | SYF508 |
| Insert | YAR208-2F |
