SKU: TMHP50/140-SKF
SKF TMHP50/140 Hydraulically Assisted Heavy Duty Jaw Pullers 310-506mm / 12.2-19.9 in
SKF TMHP50/140 Hydraulically Assisted Heavy Duty Jaw Pullers 310-506mm / 12.2-19.9 in
Regular price
€10.010,42
ex VAT
Regular price
Sale price
€10.010,42
ex VAT
In stock
Price Break
10+
€8.909,27
19+
€8.408,75
29+
€8.308,65
39+
€8.208,54
49+
€8.108,44
74+
€8.008,34
99+
€7.507,82
199+
€7.407,71
249+
€7.307,61
499+
€7.207,50
999+
€7.007,29
Couldn't load pickup availability
Description
Description
|
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing. Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.) |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| Width of Grip | 310-506mm (12.2-19.9 in.) |
|---|---|
| Effective Length of Arms | 140mm (5.5 in.) |
| Claw Height | 40mm (1.6 in.) |
| Stroke | 40mm (1.6 in.) |
| Maximum Working Pressure Hydraulic Cylinder | 80 Mpa (11 600 psi) |
| Maximum Withdrawal Force | 500 kN (56 US ton) |
