SKU: UC.210
UC210 Metric Bearing Insert with 50mm Bore 90mm Outside Dia
UC210 Metric Bearing Insert with 50mm Bore 90mm Outside Dia
Regular price
€18,69
ex VAT
Regular price
Sale price
€18,69
ex VAT
Equivalent to: 1050-50G
In stock
Price Break
10+
€16,63
19+
€15,70
29+
€15,51
39+
€15,33
49+
€15,14
74+
€14,95
99+
€14,02
199+
€13,83
249+
€13,64
499+
€13,46
999+
€13,08
Couldn't load pickup availability
Description
Description
|
UC or 10 -- G Series: Normal duty bearing insert with 2 grub screws to allow tightening against the shaft once fitted.
These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required |
Equivalent: 1050-50G
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 90mm
- Style:
- UC
- Type:
- Spherical Outer
Technical
Technical
| d | 50mm |
|---|---|
| D | 90mm |
| Bi | 51.6mm |
| Be | 24mm |
| n | 19mm |
| m | 32.6mm |
| G | 10mm |
| Grub screw | M10x1.0 |
| Weight | 0.8 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
| Rec max speed | 3400 rpm |
