SKU: UCFC.204
UCFC204 Metric Four Bolt Cast Iron Round Flanged Housing with 20mm Insert
UCFC204 Metric Four Bolt Cast Iron Round Flanged Housing with 20mm Insert
Regular price
€13,95
ex VAT
Regular price
Sale price
€13,95
ex VAT
In stock
Price Break
3+
€10,24
4+
€9,66
9+
€9,55
19+
€9,43
49+
€9,32
99+
€9,20
499+
€8,63
999+
€8,51
1999+
€8,40
2999+
€8,28
4999+
€8,05
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 20mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 78mm
Technical
Technical
| d | 20mm |
|---|---|
| a | 100mm |
| P | 78mm |
| e | 55.1mm |
| i | 10mm |
| L | 25.5mm |
| s | 12mm |
| j | 5mm |
| k | 7mm |
| g | 20.5mm |
| f | 62mm |
| z | 28.3mm |
| Bi | 31mm |
| n | 12.7mm |
| Bolt Size | M10 |
| Weight | 0.78 kg |
| Dynamic load | 1000 kgf |
| Static load | 630 kgf |
