SKU: UCFC.204-12
UCFC204-12 Imperial Four Bolt Cast Iron Round Flanged Housing with 3/4 inch Insert
UCFC204-12 Imperial Four Bolt Cast Iron Round Flanged Housing with 3/4 inch Insert
Regular price
€10,95
ex VAT
Regular price
Sale price
€10,95
ex VAT
In stock
Price Break
3+
€7,99
4+
€7,54
9+
€7,45
19+
€7,36
49+
€7,27
99+
€7,18
499+
€6,74
999+
€6,65
1999+
€6,56
2999+
€6,47
4999+
€6,29
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 19.05mm = 0.75 (3/4) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 78.18mm = 78.18 (3-5/64) inch
Technical
Technical
| d | 3/4 inch |
|---|---|
| a | 3-15/16 inch |
| P | 3-5/64 inch |
| e | 2-11/64 inch |
| i | 25/64 inch |
| L | 1 inch |
| s | 15/32 inch |
| j | 13/64 inch |
| k | 9/32 inch |
| g | 13/16 inch |
| f | 2.4409 inch |
| z | 1-1/8 inch |
| Bi | 1.2205 inch |
| n | 0.500 inch |
| Bolt Size | 3/8 inch |
| Weight | 0.78 kg |
| Dynamic load | 1000 kgf |
| Static load | 630 kgf |
