SKU: UCFC.208-24
UCFC208-24 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-1/2 inch Insert
UCFC208-24 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-1/2 inch Insert
Regular price
€27,95
ex VAT
Regular price
Sale price
€27,95
ex VAT
In stock
Price Break
3+
€21,22
4+
€20,03
9+
€19,79
19+
€19,56
49+
€19,32
99+
€19,08
499+
€17,89
999+
€17,65
1999+
€17,41
2999+
€17,17
4999+
€16,69
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 119.86mm = 119.86 (4-23/32) inch
Technical
Technical
| d | 1-1/2 inch |
|---|---|
| a | 5-23/32 inch |
| P | 4-23/32 inch |
| e | 3-11/32 inch |
| i | 7/16 inch |
| L | 1-27/64 inch |
| s | 35/64 inch |
| j | 25/64 inch |
| k | 11/32 inch |
| g | 1-1/32 inch |
| f | 3.9370 inch |
| z | 1-5/8 inch |
| Bi | 1.9370 inch |
| n | 0.7480 inch |
| Bolt Size | 7/16 inch |
| Weight | 2 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
