UCFC209 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert
UCFC209 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert
Regular price
€35,95
ex VAT
Regular price
Sale price
€35,95
ex VAT
In stock
Price Break
3+
€26,86
4+
€25,35
9+
€25,05
19+
€24,75
49+
€24,45
99+
€24,15
499+
€22,64
999+
€22,33
1999+
€22,03
2999+
€21,73
4999+
€21,13
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 45mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 132mm
Technical
Technical
| d | 45mm |
|---|---|
| a | 160mm |
| P | 132mm |
| e | 93.3mm |
| i | 10mm |
| L | 38mm |
| s | 16mm |
| j | 12mm |
| k | 10mm |
| g | 26mm |
| f | 105mm |
| z | 40.2mm |
| Bi | 49.2mm |
| n | 19mm |
| Bolt Size | M14 |
| Weight | 2.8 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
