SKU: UCFC.210-30
UCFC210-30 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-7/8 inch Insert
UCFC210-30 Imperial Four Bolt Cast Iron Round Flanged Housing with 1-7/8 inch Insert
Regular price
€41,00
ex VAT
Regular price
Sale price
€41,00
ex VAT
In stock
Price Break
10+
€36,49
19+
€34,44
29+
€34,03
39+
€33,62
49+
€33,21
74+
€32,80
99+
€30,75
199+
€30,34
249+
€29,93
499+
€29,52
999+
€28,70
Couldn't load pickup availability
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 47.63mm = 1.875 (1-7/8) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 138.11mm = 138.11 (5-7/16) inch
Technical
Technical
| d | 1-7/8 inch |
|---|---|
| a | 6-1/2 inch |
| P | 5-7/16 inch |
| e | 3-27/32 inch |
| i | 25/64 inch |
| L | 1-9/16 inch |
| s | 5/8 inch |
| j | 15/32 inch |
| k | 9/16 inch |
| g | 1-3/32 inch |
| f | 4.3307 inch |
| z | 2.0315 inch |
| Bi | 1-11/16 inch |
| n | 0.7480 inch |
| Bolt Size | 1/2 inch |
| Weight | 3 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
