SKU: UCFC.212
UCFC212 Metric Four Bolt Cast Iron Round Flanged Housing with 60mm Insert
UCFC212 Metric Four Bolt Cast Iron Round Flanged Housing with 60mm Insert
Regular price
€77,95
ex VAT
Regular price
Sale price
€77,95
ex VAT
In stock
Price Break
3+
€59,28
4+
€55,95
9+
€55,28
19+
€54,62
49+
€53,95
99+
€53,28
499+
€49,95
999+
€49,29
1999+
€48,62
2999+
€47,96
4999+
€46,62
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 60mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 160mm
Technical
Technical
| d | 60mm |
|---|---|
| a | 195mm |
| P | 160mm |
| e | 113.1mm |
| i | 17mm |
| L | 48mm |
| s | 19mm |
| j | 12mm |
| k | 15mm |
| g | 36mm |
| f | 135mm |
| z | 56.7mm |
| Bi | 65.1mm |
| n | 25.4mm |
| Bolt Size | M16 |
| Weight | 4.7 kg |
| Dynamic load | 4100 kgf |
| Static load | 3150 kgf |
