SKU: UCFC.213
UCFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Insert
UCFC213 Metric Four Bolt Cast Iron Round Flanged Housing with 65mm Insert
Regular price
€72,95
ex VAT
Regular price
Sale price
€72,95
ex VAT
In stock
Price Break
3+
€55,31
4+
€52,21
9+
€51,58
19+
€50,96
49+
€50,34
99+
€49,72
499+
€46,61
999+
€45,99
1999+
€45,37
2999+
€44,75
4999+
€43,51
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 65mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 170mm
Technical
Technical
| d | 65mm |
|---|---|
| a | 205mm |
| P | 170mm |
| e | 120.2mm |
| i | 16mm |
| L | 50mm |
| s | 19mm |
| j | 14mm |
| k | 15mm |
| g | 36mm |
| f | 145mm |
| z | 55.7mm |
| Bi | 65.1mm |
| n | 25.4mm |
| Bolt Size | M16 |
| Weight | 5.4 kg |
| Dynamic load | 4480 kgf |
| Static load | 3470 kgf |
