SKU: UCFC.213-40
UCFC213-40 Imperial Four Bolt Cast Iron Round Flanged Housing with 2-1/2 inch Insert
UCFC213-40 Imperial Four Bolt Cast Iron Round Flanged Housing with 2-1/2 inch Insert
Regular price
€44,30
ex VAT
Regular price
Sale price
€44,30
ex VAT
In stock
Price Break
10+
€39,43
19+
€37,21
29+
€36,77
39+
€36,33
49+
€35,88
74+
€35,44
99+
€33,23
199+
€32,78
249+
€32,34
499+
€31,90
999+
€31,01
Couldn't load pickup availability
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 63.5mm = 2.5 (2-1/2) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 169.86mm = 169.86 (6-11/16) inch
Technical
Technical
| d | 2-1/2 inch |
|---|---|
| a | 8-1/16 inch |
| P | 6-11/16 inch |
| e | 4-47/64 inch |
| i | 5/8 inch |
| L | 1-31/32 inch |
| s | 3/4 inch |
| j | 35/64 inch |
| k | 19/32 inch |
| g | 1-27/64 inch |
| f | 5.7087 inch |
| z | 2-3/16 inch |
| Bi | 2.5630 inch |
| n | 1 inch |
| Bolt Size | 5/8 inch |
| Weight | 5.4 kg |
| Dynamic load | 4480 kgf |
| Static load | 3470 kgf |
