SNR USF205-14 Imperial Four Bolt Square Cast Iron Flange Housing with 7/8 inch Bore Insert - Allow 2-3 Days
SNR USF205-14 Imperial Four Bolt Square Cast Iron Flange Housing with 7/8 inch Bore Insert - Allow 2-3 Days
Regular price
€25,95
ex VAT
Regular price
Sale price
€25,95
ex VAT
In stock
Price Break
3+
€21,92
4+
€21,03
9+
€20,59
19+
€19,93
49+
€19,48
99+
€18,38
499+
€15,50
999+
€0,00
1999+
€0,00
2999+
€0,00
4999+
€0,00
Description
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 22.23mm = 0.875 (7/8) inch
- Style:
- USF
- Bolt Hole Centres:
- 70mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 7/8 inch |
| A | 27mm |
| A1 | 13mm |
| A2 | 35.5mm |
| B | 27mm |
| e | 16mm |
| J | 70mm |
| L | 95mm |
| N | 12mm |
| S | 7.5mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 14 kN |
| Static load C0 | 7.88 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 3.7 Nm |
| Mass | 0.77 kg |
